OPERATING MANUAL
PART NO. 9380859017
WIRED REMOTE CONTROLLER
CONTENTS
■ SAFETY PRECAUTIONS .............................................. 3
■ SYSTEM OUTLINE ........................................................ 3
1 Terminology .................................................................... 3
2 Password configuration .................................................. 4
3 Name of parts ................................................................. 4
■ INITIALIZATION PROCEDURE .................................... 4
1-1
Monitor .................................................................... 5
1-1-1
Monitor Mode Screen ............................................... 5
1-1-2
Status Display .......................................................... 5
1-1-3
Child Lock ................................................................ 6
1-1-4
Emergency Stop....................................................... 6
2-1
On and Off ............................................................... 7
2-2
Operation Settings ................................................. 7
2-2-1
Set the Operation Mode ........................................... 7
2-2-2
Set the Temperature ................................................. 7
2-2-3
Set the Fan Speed ................................................... 7
3-1
Select the Setting Items ........................................ 8
3-2
Air Flow Direction Setting ..................................... 8
3-2-1
VT Air Flow Direction ................................................ 8
3-2-2
HZ Air Flow Direction ............................................... 8
3-3
Timer Setting .......................................................... 9
3-3-1
On Timer .................................................................. 9
3-3-2
Off Timer................................................................... 9
3-3-3
Auto Off Timer ........................................................ 10
3-4
Weekly Timer Setting (for manager) ...................11
3-4-1
Enable Schedule .................................................... 11
3-4-2
Schedule Setting .................................................... 12
3-4-3
Day Off Setting ....................................................... 13
3-5
Special Setting ......................................................14
3-5-1
Economy ................................................................ 14
3-5-2
Set Temp. Auto Return ........................................... 14
3-5-3
Set Temp. Range Setting ....................................... 15
3-5-4
Anti Freeze ............................................................. 16
3-6
Setting ....................................................................16
3-7
Preference ..............................................................16
3-7-1
Panel Calibration .................................................... 16
3-7-2
Backlight Setting .................................................... 17
3-7-3
Contrast Setting ..................................................... 18
En-1
3-8
Initial Setting ..........................................................18
3-8-1
Language Setting ................................................... 19
3-8-2
Date Setting ........................................................... 19
3-8-3
Temp. Unit Setting .................................................. 20
3-8-4
R.C.Group Name Setting ....................................... 20
3-8-5
R.C. Sensor Setting ............................................... 20
3-8-6
Master Indoor Unit Setting ..................................... 21
3-8-7
Password Setting (For Manager) ........................... 21
3-8-8
Display Item Setting ............................................... 22
3-8-9
RC Master/Slave Setting ........................................ 22
3-9
Maintenance (for manager) ................................. 23
3-9-1
Error History ........................................................... 23
3-9-2
Setting Status List .................................................. 24
3-9-3
Filter Sign Reset ..................................................... 24
3-9-4
Version ................................................................... 24
3-9-5
Test Run (for installer) ............................................ 24
3-9-6
R.C. Address Setting (for installer) ......................... 25
3-9-7
Indoor Unit Address Verification (for installer) ........ 26
3-9-8
Function Setting (for installer) ................................ 26
3-9-9
Installer Password Change .................................... 27
3-9-10 Initialization ............................................................ 27
4-1
Selectable Modes ................................................. 28
4-1-1
Heat recovery system ............................................ 28
4-1-2
in heat recovery system ......................................... 28
4-1-3
4-1-4
Heat pump system ................................................. 28
4-1-5
system .................................................................... 28
4-2
4-3
When there is no relevant function .................... 28
4-4
Settable temperature range ................................ 28
5-1
Outline Dimensions ............................................. 29
5-2
Specifications ....................................................... 29
5-3
Error Code ............................................................. 29
Advertisement
Table of Contents
Related Manuals for Fujitsu 3IVF9009
Summary of Contents for Fujitsu 3IVF9009
-
Page 1: Table Of Contents
OPERATING MANUAL Initial Setting ............18 3-8-1 Language Setting ........... 19 PART NO. 9380859017 WIRED REMOTE CONTROLLER 3-8-2 Date Setting ............19 3-8-3 Temp. Unit Setting ..........20 3-8-4 R.C.Group Name Setting ........20 CONTENTS 3-8-5 R.C. Sensor Setting ..........20 INTRODUCTION 3-8-6 Master Indoor Unit Setting ........ - Page 2 Screen structure Mode Air Flow Direction Setting VT Setting HZ Setting Cool Heat 2-2-1 Auto Cancel Back Set Temp. Timer Setting 2-2-2 26.0 On Timer [Disable] °C Off Timer [Disable] Auto Off Timer [Enable] Cancel Back 2-2-3 Weekly Timer Setting High Enable Schedule [None]...
-
Page 3: Introduction
INTRODUCTION ■ SYSTEM OUTLINE 1 Terminology ■ SAFETY PRECAUTIONS System related terms • The “SAFETY PRECAUTIONS” indicated in the manual (a) Heat recovery system: contain important information pertaining to your safety. Be The indoor unit connects to the outdoor unit via an RB sure to observe them. -
Page 4: Password Configuration
INITIALIZATION 2 Password configuration This unit can set the following 2 kinds of passwords: ■ INITIALIZATION PROCEDURE (a) Password This is a password for manager. Password is requested After remote controller installation work is complete, perform by the setting which requires management. For a initialization using the following procedures before starting to description of password setting and change, refer to [3. -
Page 5: Monitor
1 MONITOR It shows that it is time to clean the filter. Refer to [3 SETTING] → [3-9 Maintenance] → [3-9-3 Filter 1-1 Monitor Sign Reset]. The temperature sensor of this unit is used. Refer 1-1-1 Monitor Mode Screen to [3 SETTING] → [3-8 Initial Setting] → [3-8-5 R.C. Sensor Setting]. -
Page 6: Child Lock
1-1-3 Child Lock When you try to operate or set the prohibited function, the following screen is displayed and operation or setting is not possible. When the [Close] is touched, the display When this screen is displayed by touching the Monitor Mode returns to the screen before operation was performed. -
Page 7: Control
2 CONTROL 2-2-2 Set the Temperature (1) Touch the [Set Temp.] on the Monitor Mode Screen. 2-1 On and Off (1) Press the [On/Off] button. Fri 10:00AM Mode Set Temp. 26.0 Cool Auto °C Fri 10:00AM Mode Set Temp. Status Menu 26.0 Cool Auto... -
Page 8: Setting
3 SETTING 3-2-1 VT Air Flow Direction (1) Touch the [VT Setting] on the “Air Flow Direction Set- 3-1 Select the Setting Items ting” screen. (1) Touch the [Menu] on the Monitor Mode Screen. Air Flow Direction Setting VT Setting HZ Setting Fri 10:00AM Mode Set Temp. -
Page 9: Timer Setting
• Set the Operation Start Time 3-3 Timer Setting (4) Touch the [Operation Start time] on the “On Timer” (1) Touch the [Timer Setting] on the “Main Menu” screen. screen. “Operation Start time” screen is displayed. Main Manu Page 1/ 2 On Timer Fri 10:00AM Air Flow Direction... -
Page 10: Auto Off Timer
• Set the Operation Stop Time (3) “Enable/Disable” screen is displayed. Touch the [En- able]. (4) Touch the [Operation Stop time] on the "Off Timer” screen. “Operation Stop Time” screen is displayed. Enable/Disable Enable Off Timer Fri 10:00AM Enable/Disable [Enable] Disable Operation Stop Time [in 0.5 hr]... -
Page 11: Weekly Timer Setting (For Manager)
(9) Touch the [Start Time] on the “Time Range Setting” 3-4 Weekly Timer Setting (for manager) screen. Weekly operation schedule can be set. Two schedule patterns can be created. Up to 8 times setting for each day can be set. Time Range Setting Fri 10:00AM Time Range... -
Page 12: Schedule Setting
3-4-2 Schedule Setting (6) The items that can be set at one time are the [Op. Time], [On/Off], [Mode], and [Set. Temp]. When each item is touched, each setting screen is displayed. To clear the • Select the schedule to be set. setting here, when the [Clear] is touched, a verification (1) Touch the [Schedule Setting] on the “Weekly Timer Set- screen is displayed. -
Page 13: Day Off Setting
<Example program> To cancel the paste, touch the pasted day of week and touch the [Paste Clear]. Time On/Off Mode Temp. Schedule 1 Setting 08:00 28 °C Fri 10:00AM Morning [2] 10:00 AM Hold Cool 26 °C 08:00 AM On 28.0°c 12:00 PM Hold... -
Page 14: Special Setting
3-5-1 Economy (2) “Day Off Setting” screen is displayed. When the day of the week on which Weekly Timer is not to be performed is touched, a check mark is displayed. • On/Off of the Economy (1) Touch the [Economy] on the “Special Setting” screen. Day Off Setting Special Setting Sun Mon... -
Page 15: Set Temp. Range Setting
• Set the Return Time and Temperature • Enable the Set Temp. Range Setting (4) Touch the [Return Time/Return Temp.] on the “Set (2) Touch the [Enable/Disable] on the “Set Temp. Range Temp. Auto Return” screen. Setting” screen. Set Temp. Range Setting Set Temp. -
Page 16: Anti Freeze
3-5-4 Anti Freeze 3-7 Preference Settings of the Touch Panel Display (1) Touch the [Anti Freeze] on the “Special Setting” screen. When the “Password Verification” screen was displayed, (1) Touch the [Preference] on the “Main Menu” screen. enter the password and touch the [OK]. Main Manu Page 2/ 2 Special Setting... -
Page 17: Backlight Setting
(4) The [+] mark is displayed at the bottom left side of the • Enable or disable the backlight screen. Touch the center of this mark. (2) “Backlight Setting” screen is displayed. Touch the [En- able/Disable] on the “Backlight Setting” screen. Backlight Setting Enable/Disable [Enable]... -
Page 18: Contrast Setting
• Apply the setting. The following contents are set: (8) After setting is complete, touch the [OK] on the “Back- • Language Setting: light Setting” screen. The displayed language is switched. The displayable languages are English (factory setting), Chinese, Backlight Setting French, German, Spanish, Polish, and Russian. -
Page 19: Language Setting
3-8-1 Language Setting (5) Touch the [Time] on the “Date and Time Setting” screen. (1) Touch the [Language Setting] on the “Initial Setting” Date and Time Setting Fri 10:00AM Date Time screen. “Language Setting” screen is displayed. 14/ 9/2012 10:00 AM Date Format Day/Month/Year Initial Setting... -
Page 20: Temp. Unit Setting
• Description of the screen (12) “Time Format” screen is displayed. Select the desired format. R.C.Group Name Setting Time Format Fri 10:00AM ABCDEFGHIJKLM│ Over 12:00–11:59 AM/PM 0:00–11:59 AM/PM 0:00–23:59 Cancel Fixed 0–9 _– Phrase When the [OK] is touched, the display returns to the “Display Format Setting”... -
Page 21: Master Indoor Unit Setting
3-8-6 Master Indoor Unit Setting (3) “Password Verification” screen is displayed. Enter the current password, and touch the [OK]. (1) Touch the [Master Indoor Unit Setting] on the “Initial Setting” screen. Password Verification Enter Current Password Initial Setting Page 2/ 3 R.C. -
Page 22: Display Item Setting
• Apply the setting. (5) “Room Temp.” screen is displayed. Select the [Visible] or [Invisible]. (8) When setting is complete, touch the [OK] on the “Change Setting” screen. Room Temp. (Ex. Page 1/3) Visible Change Setting Page 1/ 3 Invisble On Timer [Off] Off Timer... -
Page 23: Maintenance (For Manager)
• Initialization: All the settings of this unit is returned to their factory 3-9 Maintenance (for manager) state. This setting requires an installer password. Verification, operation, and setting for manager information When the [Back] is touched at settings other than initial- are performed. -
Page 24: Setting Status List
3-9-2 Setting Status List 3-9-4 Version (1) Touch the [Setting Status List] on the “Maintenance” (1) Touch the [Version] on the “Maintenance” screen. screen. Maintenance Page 1/ 3 Setting Maintenance Page 1/ 3 Error History Status List Setting Error History Status List Filter Sign Version... -
Page 25: Address Setting (For Installer)
3-9-6 R.C. Address Setting (for installer) (2) “Manual Addressing” screen is displayed. Set the ad- dress with [ ] or [ ]. (1) When the [RC Address Setting] on the “Maintenance” screen is touched, the “Installer Password Verification” Manual Addressing System Unit screen is displayed. -
Page 26: Indoor Unit Address Verification (For Installer)
3-9-7 Indoor Unit Address Verification (for installer) (6) When the [End] is touched, the display returns to the screen of (2). (1) Touch the [I.U. Address Verification] on the “Mainte- I.U. Address Verification Page 1/ 2 nance” screen. “Installer Password Verification” screen No. -
Page 27: Installer Password Change
(5) “Function No.” screen is displayed. Set the Function No. (2) “Installer Password Verification” screen is displayed. with the [ ] or [ ]. Enter the Current Password, and touch the [OK]. Function No. Installer Password Verification Enter Current Password Cancel Cancel When the [OK] is touched, the display returns to the... -
Page 28: Operation Tips
4 OPERATION TIPS 4-1-5 Outdoor unit priority connection in heat pump system 4-1 Selectable Modes (a) Refer to the following table: There are restrictions on the selectable modes depending on Status Selectable Not selectable the system configuration and operation status. Cooling priority is set by exter- Cool, Dry Auto, Heat, 4-1-1 Heat recovery system... -
Page 29: Others
5 OTHERS 5-1 Outline Dimensions Unit: mm (in.) 120 (4-23/32) 20.4 (13/16) 5-2 Specifications UTY-RNRY Model Name UTY-RNRG Input voltage DC 12 V Power consumption Max. 0.3 W 3.8 inch FSTN LCD display Display (255 × 160 dots) with Touch panel 0 to 40 °C Usage temperature range (32 to 104 °F)
