6.5 Group 3.5: I/O Configuration

Table 44: Digital Input Settings
Index Parameter
P3.5.1.1 Control Signal 1 A
P3.5.1.2 Control Signal 2 A
P3.5.1.3 Control Signal 3 A
P3.5.1.4 Control Signal 1 B
P3.5.1.5 Control Signal 2 B
P3.5.1.6 Control Signal 3 B
P3.5.1.7 I/O B Control Force
P3.5.1.8 I/O B Reference Force
P3.5.1.9 Fieldbus Control Force
P3.5.1.10 Keypad Control Force
P3.5.1.11 External Fault Close
P3.5.1.12 External Fault Open
P3.5.1.13 Fault Reset Close
P3.5.1.14 Fault Reset Open
P3.5.1.15 Run Enable
P3.5.1.16 Run Interlock 1
P3.5.1.17 Run Interlock 2
P3.5.1.18 Motor Preheat ON
P3.5.1.19 Ramp 2 Selection
P3.5.1.20 Acc/Dec Prohibit
Danfoss A/S © 2023.08
Min Max Unit Default
DigIN SlotA.1
DigIN SlotA.2
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN SlotA.3
DigIN Slot0.2
Varies
DigIN Slot0.1
DigIN Slot0.2
DigIN Slot0.2
DigIN Slot0.2
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
ID Description
(1)
403
(1)
404
434
(1)
423
(1)
424
435
(1)
425 CLOSED = Force the control place to
I/O B
(1)
343 CLOSED = I/O reference B (P3.3.1.6)
gives the frequency reference
(1)
411
(1)
410
(1)
405 OPEN = OK
CLOSED = External fault
406 OPEN = External fault
CLOSED = OK
414 CLOSED = Resets all active faults
213 OPEN = Resets all active faults
407
1041
1042
1044 OPEN = No action
CLOSED = Uses the DC current of the
motor preheat in Stop state. Used
when the value of P3.18.1 is 2.
408 OPEN = Ramp 1 Shape, Acceleration
Time 1, and Deceleration Time 1.
CLOSED = Ramp 2 Shape, Accelera-
tion Time 2, and Deceleration Time 2.
415
