P3.2.7 I/O B Start/Stop Logic
P3.2.8 Fieldbus Start Logic
P3.2.9 Start Delay
P3.2.10 Remote to Local Function
P3.2.11 Restart Delay
The selection of the application with parameter P1.2 Application gives the default value. See
1
Applications.

6.3 Group 3.3: References

Table 35: Frequency Reference Parameters
Index Parameter
P3.3.1.1 Minimum Frequency Reference
P3.3.1.2 Maximum Frequency Reference
P3.3.1.3 Positive Frequency Reference Limit
P3.3.1.4 Negative Frequency Reference Limit
P3.3.1.5 I/O Control Reference A Selection
Danfoss A/S © 2023.08
Min Max Unit Default
2
0 4
0 1 0
0.000 60.000 s 0.000
0 2 2
0.0 20.0 min 0.0
Min Max
0.00 P3.3.1.2
P3.3.1.1 320.00
-320.0 320.0
-320.0 320.0
1 20
ID Description
• Ctrl sgn 1 = Start (edge)
• Ctrl sgn 2 = Reverse
(1)
363 See P3.2.6.
889 0 = A rising edge is necessary
1 = State
524
181 0 = Keep Run
1 = Keep Run & Reference
2 = Stop
15555 0 = Not used
11.25 Default Values of Parameters in the Different
Unit Default ID
Hz 0.00 101
Hz 50.00/60.00 102
Hz 320.00 1285
Hz -320.00 1286
6
(1)
117
AB298035655957en-000201 / DPD01083 | 91
Parameters Menu
Description
1 = Preset Frequency 0
2 = Keypad reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID reference
8 = Motor potentiometer
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
