VACON® 100 FLOW
Application Guide
Table 113: Option Board Related Parameters
Menu Function
Slot C Settings
Monitoring
Slot D Settings
Monitoring
Slot E Settings
Monitoring

8.3 Real-time Clock

Table 114: The Real-time Clock Parameters in the I/O and Hardware Menu
Index Parameter Min
V5.5.1 Battery 1
State
P5.5.2 Time
P5.5.3 Date
P5.5.4 Year
P5.5.5 Daylight 1
Saving

8.4 Simple Network Time Protocol (SNTP)

The simple network time protocol (SNTP) allows devices connected to a TCP/IP network receive precise time information from des-
ignated time servers. The time information can be received either by the client device polling the time servers or the time servers
broadcasting the time.
Table 115: SNTP parameters
Index Parameter
V5.5.7.1.1 SNTP Mode
V5.5.7.1.2 Server 1 IP
V5.5.7.1.3 Server 2 IP
V5.5.7.1.4 SNTP Port
V5.5.7.1.5 Time Interval
Danfoss A/S © 2023.08
Description
The settings that are related to the option board.
Monitor the data that is related to the option board.
The settings that are related to the option board.
Monitor the data that is related to the option board.
The settings that are related to the option board.
Monitor the data that is related to the option board.
Max Unit De-
fault
3
hh:mm:ss
dd.mm.
yyyy
4
Min Max
ID Description
2205
Status of the battery.
1 = Not installed
2 = Installed
3 = Replace the battery
2201 The current time of the day
2202 The current date
2203 The current year
2204
The daylight saving rule
1 = Off
2 = EU: starts on the last Sunday in March, ends on the last
Sunday in October
3 = US: starts on the 2nd Sunday in March, ends on the 1st
Sunday in November
4 = Russia (permanent)
Unit Default
I/O and Hardware Menu
ID Description
3162
3163
3164
3165
3166
AB298035655957en-000201 / DPD01083 | 141
