VACON® 100 FLOW
Application Guide
Index Parameter
P3.8.6 Supervision #2 Mode
P3.8.7 Supervision #2 Limit
P3.8.8 Supervision #2 Limit Hysteresis

6.9 Group 3.9: Protections

Table 57: General Protection Settings
Index Parameter
P3.9.1.2 Response to External Fault
P3.9.1.3 Input Phase Fault
P3.9.1.4 Undervoltage Fault
P3.9.1.5 Response to Output Phase
Fault
P3.9.1.6 Response to Fieldbus Com-
munication Fault
P3.9.1.7 Slot Communication Fault
P3.9.1.8 Thermistor Fault
P3.9.1.9 PID Soft Fill Fault
P3.9.1.10 Response to PID Supervision
Fault
P3.9.1.11 Response to External PID Su-
pervision Fault
P3.9.1.12 Earth Fault
P3.9.1.13 Preset Alarm Frequency
Danfoss A/S © 2023.08
Min Max Unit
0 2
-50.00 50.00 Varies
0.00 50.00 Varies
Min Max Unit Default
0 3 2
0 1 0
0 1 0
0 3 2
0 5 4
0 3 2
0 3 0
0 3 2
0 3 2
0 3 2
0 3 3
P3.3.1.1 P3.3.1.2 Hz 25.00
Default ID Description
0 1436 See P3.8.2
40.00 1437
5.00 1438
ID Description
701 0 = No action
1 = Alarm
2 = Fault (Stop according to stop func-
tion)
3 = Fault (Stop by coasting)
730 0 = 3-phase support
1 = 1-phase support
727 0 = Fault stored in history
1 = Fault not stored in history
702 See P3.9.1.2.
733 0 = No action
1 = Alarm
2 = Alarm + preset fault frequency
(P3.9.1.13)
3 = Fault (Stop according to stop func-
tion)
4 = Fault (Stop by coasting)
734 See P3.9.1.2.
732 See P3.9.1.2.
748 See P3.9.1.2.
749 See P3.9.1.2.
757 0 = No action
1 = Alarm
2 = Fault
3 = Fault, Coast
703 This parameter is available only in enclo-
sure sizes MR7, MR8, MR9, MR10, MR11,
and MR12, and also MR6 600 V and 690 V.
183
AB298035655957en-000201 / DPD01083 | 105
