RM0401
16.3.12

Debug mode

When the microcontroller enters debug mode (Cortex
counter either continues to work normally or stops, depending on DBG_TIMx_STOP
configuration bit in DBGMCU module. For more details, refer to
support for timers, watchdog, and
16.4

TIM9 registers

Refer to
The peripheral registers have to be written by half-words (16 bits) or words (32 bits). Read
accesses can be done by bytes (8 bits), half-words (16 bits) or words (32 bits).
16.4.1

TIM9 control register 1 (TIMx_CR1)

Address offset: 0x00
Reset value: 0x0000
15 14 13
Res. Res. Res. Res.
Bits 15:10 Reserved, must be kept at reset value.
Bits 9:8 CKD: Clock division
Bit 7 ARPE: Auto-reload preload enable
Bits 6:4 Reserved, must be kept at reset value.
Bit 3 OPM: One-pulse mode
Section 1.2 on page 34
12 11 10 9
Res. Res. CKD[1:0]
rw
This bit-field indicates the division ratio between the timer clock (CK_INT) frequency and
sampling clock used by the digital filters (TIx),
00: t = t
DTS CK_INT
01: t = 2 × t
DTS CK_INT
10: t = 4 × t
DTS CK_INT
11: Reserved
0: TIMx_ARR register is not buffered.
1: TIMx_ARR register is buffered.
0: Counter is not stopped on the update event
1: Counter stops counting on the next update event (clearing the CEN bit).
General-purpose timers (TIM9 and TIM11)
®
I2C.
for a list of abbreviations used in register descriptions.
8 7 6
ARPE Res.
rw rw
RM0401 Rev 3
-M4 with FPU core halted), the TIMx
Section 26.16.2: Debug
5 4 3 2
Res. Res. OPM URS
rw rw
1 0
UDIS CEN
rw rw
411/771
