Reset and clock control (RCC)
5.3.3

RCC clock configuration register (RCC_CFGR)

Address offset: 0x08
Reset value: 0x0000 0000
Access: 0
1 or 2 wait states inserted only if the access occurs during a clock source switch.
31 30 29
MCO2 MCO2 PRE[2:0]
rw rw
15 14 13
PPRE2[2:0]
rw rw rw
Bits 31:30 MCO2[1:0]: Microcontroller clock output 2
Set and cleared by software. Clock source selection may generate glitches on MCO2. It is
highly recommended to configure these bits only after reset before enabling the external
oscillators and the PLLs.
00: System clock (SYSCLK) selected
01: Main PLL clock (I2S)
10: HSE oscillator clock selected
11: PLL clock selected
Bits 29:27 MCO2PRE: MCO2 prescaler
Set and cleared by software to configure the prescaler of the MCO2. Modification of this
prescaler may generate glitches on MCO2. It is highly recommended to change this
prescaler only after reset before enabling the external oscillators and the PLLs.
0xx: no division
100: division by 2
101: division by 3
110: division by 4
111: division by 5
Bits 26:24 MCO1PRE: MCO1 prescaler
Set and cleared by software to configure the prescaler of the MCO1. Modification of this
prescaler may generate glitches on MCO1. It is highly recommended to change this
prescaler only after reset before enabling the external oscillators and the PLL.
0xx: no division
100: division by 2
101: division by 3
110: division by 4
111: division by 5
Bit 23 Reserved, must be kept at reset value.
106/771
wait state 2, word, half-word and byte access
≤ ≤
28 27 26 25
MCO1 PRE[2:0]
rw rw rw rw
12 11 10 9
MCO2
PPRE1[2:0]
EN
rw
rw rw rw
24 23 22
Res. MCO1
rw rw
8 7 6
MCO1
HPRE[3:0]
EN
rw
rw rw
RM0401 Rev 3
21 20 19 18
RTCPRE[4:0]
rw rw rw
5 4 3 2
SWS1 SWS0
rw rw r r
RM0401
17 16
rw rw
1 0
SW1 SW0
rw rw
