Universal synchronous receiver transmitter (USART) /universal asynchronous receiver transmit-
24.6.2

Data register (USART_DR)

Address offset: 0x04
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:9 Reserved, must be kept at reset value
Bits 8:0 DR[8:0]: Data value
24.6.3

Baud rate register (USART_BRR)

Note: The baud counters stop counting if the TE or RE bits are disabled respectively.
Address offset: 0x08
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:16 Reserved, must be kept at reset value
Bits 15:4 DIV_Mantissa[11:0]: mantissa of USARTDIV
Bits 3:0 DIV_Fraction[3:0]: fraction of USARTDIV
672/771
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. Res. Res.
Contains the Received or Transmitted data character, depending on whether it is read from
or written to.
The Data register performs a double function (read and write) since it is composed of two
registers, one for transmission (TDR) and one for reception (RDR)
The TDR register provides the parallel interface between the internal bus and the output shift
register (see Figure 1).
The RDR register provides the parallel interface between the input shift register and the
internal bus.
When transmitting with the parity enabled (PCE bit set to 1 in the USART_CR1 register), the
value written in the MSB (bit 7 or bit 8 depending on the data length) has no effect because
it is replaced by the parity.
When receiving with the parity enabled, the value read in the MSB bit is the received parity
bit.
28 27 26 25
Res. Res. Res.
12 11 10 9
DIV_Mantissa[11:0]
rw rw rw rw
These 12 bits define the mantissa of the USART Divider (USARTDIV)
These 4 bits define the fraction of the USART Divider (USARTDIV). When OVER8=1, the
DIV_Fraction3 bit is not considered and must be kept cleared.
24 23 22
Res. Res. Res. Res.
8 7 6
rw rw rw
24 23 22
Res. Res. Res.
8 7 6
rw rw rw
RM0401 Rev 3
21 20 19 18
Res. Res. Res.
5 4 3 2
DR[8:0]
rw rw rw rw
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
DIV_Fraction[3:0]
rw rw rw rw
17 16
Res. Res.
1 0
rw rw
17 16
Res. Res.
1 0
rw rw
