Reset and clock control (RCC)
5.3.18

RCC dedicated Clocks Configuration Register 2 (RCC_DCKCFGR2)

Address offset: 0x94
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access.
31
30
29
28
LPTIM1SEL
Res.
Res.
rw
rw
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:30 LPTIMSEL: LPTIM1 kernel clock source selection
Bits 29:24 Reserved, must be kept at reset value.
Bits 23:22 I2C4SEL: I2C4 kernel clock source selection
Bits 21: 0 Reserved, must be kept at reset value.
132/771
27
26
25
Res.
Res.
Res.
11
10
9
Res.
Res.
Res.
Set and reset by software to select the LPTIM1 clock source.
00: LPTIM1 clock = APB clock
01: LPTIM1 clock = HSI clock
10: LPTIM1 clock = LSI clock
11: LPTIM1 clock = LSE clock
Set and reset by software to select the I2C4 clock source.
00 and 11: I2C4 clock = APB clock
01: I2C4 clock = system clock
10: I2C4 clock = HSI clock
24
23
22
21
Res.
I2C4SEL
Res.
rw
rw
8
7
6
Res.
Res.
Res.
Res.
RM0401 Rev 3
20
19
18
Res.
Res.
Res.
5
4
3
2
Res.
Res.
Res.
RM0401
17
16
Res.
Res.
1
0
Res.
Res.
