System and memory overview

2 System and memory overview
2.1

System architecture

In STM32F410, the main system consists of 32-bit multilayer AHB bus matrix that
interconnects:
•
Six masters:
–
–
–
–
• Five slaves:
–
–
–
–
–
The bus matrix provides access from a master to a slave, enabling concurrent access and
efficient operation even when several high-speed peripherals work simultaneously. This
architecture is shown in
1. The Flash memory size is 512 Kbytes or 128 Mbytes while SRAM1 size is 256 Kbytes.
36/771
®
Cortex -M4 with FPU core I-bus, D-bus and S-bus
DMA1 memory bus
DMA2 memory bus
DMA2 peripheral bus
Internal Flash memory ICode bus
Internal Flash memory DCode bus
Main internal SRAM
AHB1 peripherals including AHB to APB bridges and APB peripherals
AHB2 peripherals
Figure

Figure 1. System architecture

1.
RM0401 Rev 3
RM0401
