RM0401
21.6.2

RTC date register (RTC_DR)

The RTC_DR is the calendar date shadow register. This register must be written in
initialization mode only. Refer to
calendar.
Address offset: 0x04
Backup domain reset value: 0x0000_2101
System reset: 0x0000 2101 when BYPSHAD = 0. Not affected when BYPSHAD = 1.
31 30 29
Res. Res. Res. Res.
15 14 13
WDU[2:0]
rw rw rw
Bits 31-24 Reserved, must be kept at reset value
Bits 23:20 YT[3:0]: Year tens in BCD format
Bits 19:16 YU[3:0]: Year units in BCD format
Bits 15:13 WDU[2:0]: Week day units
Bit 12 MT: Month tens in BCD format
Bits 11:8 MU: Month units in BCD format
Bits 7:6 Reserved, must be kept at reset value.
Bits 5:4 DT[1:0]: Date tens in BCD format
Bits 3:0 DU[3:0]: Date units in BCD format
Note: This register is write protected. The write access procedure is described in
write protection.
28 27 26 25
Res. Res. Res.
12 11 10 9
MT MU[3:0]
rw rw rw rw
000: forbidden
001: Monday
...
111: Sunday
Calendar initialization and configuration
24 23 22
Res. YT[3:0]
rw rw
8 7 6
Res. Res.
rw
RM0401 Rev 3
Real-time clock (RTC)
and
21 20 19 18
YU[3:0]
rw rw rw rw
5 4 3 2
DT[1:0] DU[3:0]
rw rw rw rw
RTC register
Reading the
17 16
rw rw
1 0
rw rw
503/771
