General-purpose timers (TIM2 to TIM5)
18.4.20

TIM5 option register (TIM5_OR)

Address offset: 0x50
Reset value: 0x0000
15 14 13
Bits 15:8 Reserved, must be kept at reset value.
Bits 7:6 TI4_RMP: Timer Input 4 remap
Set and cleared by software.
00: TIM5 Channel4 is connected to the GPIO: Refer to the Alternate function mapping table
in the datasheets.
01: the LSI internal clock is connected to the TIM5_CH4 input for calibration purposes
10: the LSE internal clock is connected to the TIM5_CH4 input for calibration purposes
11: the RTC wakeup interrupt is connected to TIM5_CH4 input for calibration purposes.
Wakeup interrupt should be enabled.
Bits 5:0 Reserved, must be kept at reset value.
638/1731
12 11 10 9
Reserved
DocID018909 Rev 11
8 7 6 5
TI4_RMP
rw rw
RM0090
4 3 2 1
Reserved
0
