LCD-TFT Controller (LTDC)
Interrupt event
Line
Register Reload
FIFO Underrun
Transfer Error
16.6

LTDC programming procedure

Enable the LTDC clock in the RCC register
Configure the required Pixel clock following the panel datasheet
Configure the Synchronous timings: VSYNC, HSYNC, Vertical and Horizontal back
porch, active data area and the front porch timings following the panel datasheet as
described in the
Configure the synchronous signals and clock polarity in the LTDC_GCR register
If needed, configure the background color in the LTDC_BCCR register
Configure the needed interrupts in the LTDC_IER and LTDC_LIPCR register
Configure the Layer1/2 parameters by programming:
Enable Layer1/2 and if needed the CLUT in the LTDC_LxCR register
If needed, dithering and color keying can be enabled respectively in the LTDC_GCR
and LTDC_LxCKCR registers. It can be also enabled on the fly.
Reload the shadow registers to active register through the LTDC_SRCR register.
Enable the LCD-TFT controller in the LTDC_GCR register.
All layer parameters can be modified on the fly except the CLUT. The new configuration
has to be either reloaded immediately or during vertical blanking period by configuring
the LTDC_SRCR register.
Note:
All layer's registers are shadowed. Once a register is written, it should not be modified again
before the reload has been done. Thus, a new write to the same register will override the
previous configuration if not yet reloaded.
490/1731

Table 90. LTDC interrupt requests

Section 16.4.1: LTDC Global configuration parameters
The Layer window horizontal and vertical position in the LTDC_LxWHPCR and
LTDC_WVPCR registers. The layer window must be in the active data area.
The pixel input format in the LTDC_LxPFCR register
The color frame buffer start address in the LTDC_LxCFBAR register
The line length and pitch of the color frame buffer in the LTDC_LxCFBLR register
The number of lines of the color frame buffer in the LTDC_LxCFBLNR register
if needed, load the CLUT with the RGB values and its address in the
LTDC_LxCLUTWR register
If needed, configure the default color and the blending factors respectively in the
LTDC_LxDCCR and LTDC_LxBFCR registers
DocID018909 Rev 11
Event flag
LIF
RRIF
FUDERRIF
TERRIF
RM0090
Enable Control bit
LIE
RRIEN
FUDERRIE
TERRIE
