RM0090
Reset and clock control for STM32F405xx/07xx and STM32F415xx/17xx(RCC)
7.3.20
RCC APB2 peripheral clock enabled in low power mode
register (RCC_APB2LPENR)
Address offset: 0x64
Reset value: 0x0407 5F33
Access: no wait state, word, half-word and byte access.
31
30
29
28
15
14
13
12
SYSC
SPI1
FG
Reser-
Reser-
LPEN
LPEN
ved
ved
rw
rw
Bits 31:19 Reserved, must be kept at reset value.
Bit 18 TIM11LPEN: TIM11 clock enable during Sleep mode
Bit 17 TIM10LPEN: TIM10 clock enable during Sleep mode
Bit 16 TIM9LPEN: TIM9 clock enable during sleep mode
Bit 15 Reserved, must be kept at reset value.
Bit 14 SYSCFGLPEN: System configuration controller clock enable during Sleep mode
Bit 13 Reserved, must be kept at reset value.
Bit 12 SPI1LPEN: SPI1 clock enable during Sleep mode
Bit 11 SDIOLPEN: SDIO clock enable during Sleep mode
27
26
25
Reserved
11
10
9
SDIO
ADC3
ADC2
LPEN
LPEN
LPEN
rw
rw
rw
Set and cleared by software.
0: TIM11 clock disabled during Sleep mode
1: TIM11 clock enabled during Sleep mode
Set and cleared by software.
0: TIM10 clock disabled during Sleep mode
1: TIM10 clock enabled during Sleep mode
Set and cleared by software.
0: TIM9 clock disabled during Sleep mode
1: TIM9 clock enabled during Sleep mode
Set and cleared by software.
0: System configuration controller clock disabled during Sleep mode
1: System configuration controller clock enabled during Sleep mode
Set and cleared by software.
0: SPI1 clock disabled during Sleep mode
1: SPI1 clock enabled during Sleep mode
Set and cleared by software.
0: SDIO module clock disabled during Sleep mode
1: SDIO module clock enabled during Sleep mode
DocID018909 Rev 11
24
23
22
21
8
7
6
5
USART
ADC1
6
LPEN
Reserved
LPEN
rw
rw
20
19
18
TIM11
TIM10
LPEN
LPEN
rw
4
3
2
USART
TIM8
1
LPEN
Reserved
LPEN
rw
17
16
TIM9
LPEN
rw
rw
1
0
TIM1
LPEN
rw
rw
259/1731
268
