14.5.9 Dual DAC 12-bit right-aligned data holding register
(DAC_DHR12RD)
Address offset: 0x20
Reset value: 0x0000 0000
31 30 29 28
Reserved
15 14 13 12
Reserved
Bits 31:28 Reserved, must be kept at reset value.
Bits 27:16 DACC2DHR[11:0]: DAC channel2 12-bit right-aligned data
Bits 15:12 Reserved, must be kept at reset value.
Bits 11:0 DACC1DHR[11:0]: DAC channel1 12-bit right-aligned data
14.5.10 DUAL DAC 12-bit left aligned data holding register
(DAC_DHR12LD)
Address offset: 0x24
Reset value: 0x0000 0000
31 30 29 28
rw rw rw
15 14 13 12
rw rw rw
Bits 31:20 DACC2DHR[11:0]: DAC channel2 12-bit left-aligned data
Bits 19:16 Reserved, must be kept at reset value.
Bits 15:4 DACC1DHR[11:0]: DAC channel1 12-bit left-aligned data
Bits 3:0 Reserved, must be kept at reset value.
27 26 25
rw rw rw
11 10 9
rw rw rw
These bits are written by software which specifies 12-bit data for DAC channel2.
These bits are written by software which specifies 12-bit data for DAC channel1.
27 26 25
DACC2DHR[11:0]
rw rw rw rw
11 10 9
DACC1DHR[11:0]
rw rw rw rw
These bits are written by software which specifies 12-bit data for DAC channel2.
These bits are written by software which specifies 12-bit data for DAC channel1.
