Chrom-Art Accelerator™ controller (DMA2D)
11.5.19

DMA2D line watermark register (DMA2D_LWR)

Address offset: 0x0048
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
rw rw rw rw
Bits 31:16 Reserved, must be kept at reset value
Bits 15:0 LW[15:0]: Line watermark
11.5.20 DMA2D AHB master timer configuration register (DMA2D_AMTCR)
Address offset: 0x004C
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
rw rw rw rw
Bits 31:16 Reserved
Bits 15:8 DT[7: 0]: Dead Time
Bits 7:1 Reserved
Bit 0 EN: Enable
370/1731
27 26 25
11 10 9
rw rw rw
These bits allow to configure the line watermark for interrupt generation.
An interrupt is raised when the last pixel of the watermarked line has been transferred.
These bits can only be written when data transfers are disabled. Once the transfer has
started, they are read-only.
27 26 25
11 10 9
DT[7:0]
rw rw rw
Dead time value in the AHB clock cycle inserted between two consecutive accesses on
the AHB master port. These bits represent the minimum guaranteed number of cycles
between two consecutive AHB accesses.
Enables the dead time functionality.
