11.3.8

DMA2D output FIFO

The output FIFO programs the pixels according to the color format defined in the output
PFC.
The destination area is defined through a set of control registers:
• DMA2D output memory address register (DMA2D_OMAR)
•
DMA2D output offset register (DMA2D_OOR)
• DMA2D number of lines register (number of lines and pixel per lines) (DMA2D_NLR)
If the DMA2D operates in register-to-memory mode, the configured output rectangle is filled
by the color specified in the DMA2D output color register (DMA2D_OCOLR) which contains
a fixed 32-bit, 24-bit or 16-bit value. The format is selected by the CM[2:0] field of the
DMA2D_OPFCCR register.
The data are stored into the memory in the order defined in
Color Mode
ARGB8888
RGB888
RGB565
ARGB1555
ARGB4444
The RGB888 aligned on 32-bit is supported through the ARGB8888 mode.
11.3.9 DMA2D AHB master port timer
An 8-bit timer is embedded into the AHB master port to provide an optional limitation of the
bandwidth on the crossbar.
This timer is clocked by the AHB clock and counts a dead time between two consecutive
accesses. This limits the bandwidth usage.
