RM0090
Bit 5 HASHEN: Hash modules clock enable
Bit 4 CRYPEN: Cryptographic modules clock enable
Bits 3:1 Reserved, must be kept at reset value.
Bit 0 DCMIEN: Camera interface enable
6.3.12

RCC AHB3 peripheral clock enable register (RCC_AHB3ENR)

Address offset: 0x38
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access.
31 30 29
15 14 13
Bits 31:1 Reserved, must be kept at reset value.
Bit 0 FMCEN: Flexible memory controller module clock enable
6.3.13

RCC APB1 peripheral clock enable register (RCC_APB1ENR)

Address offset: 0x40
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access.
31 30 29
DAC PWR
UART8 UART7
EN EN
EN
rw rw rw
15 14 13
SPI3 SPI2
EN EN
Reserved
rw rw
Reset and clock control for STM32F42xxx and STM32F43xxx (RCC)
This bit is set and cleared by software.
0: Hash modules clock disabled
1: Hash modules clock enabled
This bit is set and cleared by software.
0: cryptographic module clock disabled
1: cryptographic module clock enabled
This bit is set and cleared by software.
0: Camera interface clock disabled
1: Camera interface clock enabled
28 27 26 25
12 11 10 9
This bit is set and cleared by software.
0: FMC module clock disabled
1: FMC module clock enabled
28 27 26 25
CAN2 CAN1
Reser-
EN EN EN
ved
rw rw rw
12 11 10 9
WWDG
EN
Reserved
rw
DocID018909 Rev 11
24 23 22
Reserved
8 7 6
Reserved
24 23 22 21
I2C3 I2C2 I2C1
Reser-
EN EN EN
ved
rw rw
8 7 6
TIM14 TIM13 TIM12 TIM7
EN EN EN EN
rw rw rw
21 20 19 18
5 4 3 2
20 19 18
USART
UART5 UART4
3
EN EN
EN
rw rw rw rw
5 4 3 2
TIM6 TIM5 TIM4
EN EN EN
rw rw rw rw
17 16
1 0
FMCEN
rw
17 16
USART
2
Reser-
EN
ved
rw
1 0
TIM3 TIM2
EN EN
rw rw
183/1731
