System configuration controller (SYSCFG)
Bits 31:2 Reserved, must be kept at reset value.
9.2.2

SYSCFG peripheral mode configuration register (SYSCFG_PMC)

Address offset: 0x04
Reset value: 0x0000 0000
31 30 29
15 14 13
Bits 31:24 Reserved, must be kept at reset value.
Bits 22:0 Reserved, must be kept at reset value.
292/1731
Bits 1:0 MEM_MODE: Memory mapping selection
Set and cleared by software. This bit controls the memory internal mapping at
address 0x0000 0000. After reset these bits take the value selected by the Boot
pins (except for FSMC).
00: Main Flash memory mapped at 0x0000 0000
01: System Flash memory mapped at 0x0000 0000
10: FSMC Bank1 (NOR/PSRAM 1 and 2) mapped at 0x0000 0000
11: Embedded SRAM (SRAM1) mapped at 0x0000 0000
Note: Refer to
address 0x0000 0000.
28 27 26 25
Reserved
12 11 10 9
Bit 23 MII_RMII_SEL: Ethernet PHY interface selection
Set and Cleared by software.These bits control the PHY interface for the
Ethernet MAC.
0: MII interface is selected
1: RMII PHY interface is selected
Note: This configuration must be done while the MAC is under reset and before
enabling the MAC clocks.
DocID018909 Rev 11
Section 2.3: Memory map
24 23 22
MII_RMII
_SEL
rw
8 7 6
Reserved
for details about the memory mapping at
21 20 19 18
Reserved
5 4 3 2
RM0090
17 16
1 0
