Unit Time
d day(s)

Setting Thresholds for Total Active Energy or Power

This section applies only to multi‑inlet models, including in‑line monitors.
Thresholds for total active energy and total active power are disabled by default. You can enable and set
them so that you are alerted when the total active energy or total active power hits a certain level.
For a regular PRO3X model with multiple inlets:
• •
Total active energy = sum of all inlets' active energy values
• •
Total active power = sum of all inlets' active power values
For an in‑line monitor with multiple inlets/outlets:
• • Total active energy = sum of all outlets' active energy values
• •
Total active power = sum of all outlets' active power values
▶
To configure thresholds for total active energy and/or power:
1) Click PDU.
2) Click the Thresholds title bar at the bottom of the page to display thresholds.
3) Click a sensor to edit the thresholds.
4) Make changes as needed.
• • To enable any threshold, select the corresponding checkbox.
• Type a new value in the accompanying text box. •
98
