PRO3X can monitor any IT device, such as database servers, remote authentication servers, power
distribution units (PDUs), and so on. It supports monitoring a maximum of 64 IT devices.
To perform this feature, you need the Administrator Privileges.
The default ping settings may not be suitable for monitoring devices that require high connection
reliability so it is strongly recommended that you should adjust the ping settings for optimal results.
In addition, if your PRO3X is outlet switching capable, you can even connect a monitored IT device to
one or multiple outlets of PRO3X and then have PRO3X perform the following two actions as needed, in
addition to monitoring its status:
• •
First shut down the monitored IT device.
• •
After the IT device is shut down, power off the outlet(s) where that device is connected.
Important: Not every IT device can be shut down by PRO3X so it is suggested to
verify whether the device can be shut down using a shutdown command. For
example, PRO3X cannot shut down a PDU with a shutdown command.
▶
To add IT equipment for ping monitoring:
1) Choose Device Settings > Server Reachability.
2) Click
3) By default, the "Enable ping monitoring for this server" checkbox is selected. If not, select it to
enable this feature.
4) Configure the following.
Field
IP address/hostname
Number of successful
pings to enable feature
Wait time after
successful ping
Wait time after
unsuccessful ping
Number of consecutive
unsuccessful pings for
failure
Wait time before
resuming pinging after
failure
.
Description
IP address or host name of the IT equipment which you
want to monitor.
The number of successful pings required to declare
that the monitored equipment is "Reachable." Valid
range is 0 to 200.
The wait time before sending the next ping if the
previous ping was successfully responded. Valid range
is 5 to 600 (seconds).
The wait time before sending the next ping if the
previous ping was not responded. Valid range is 3 to
600 (seconds).
The number of consecutive pings without any response
before the monitored equipment is declared
"Unreachable." Valid range is 1 to 100.
The wait time before the PRO3X resumes pinging after
the monitored equipment is declared "Unreachable."
Valid range is 1 to 1200 (seconds).
