2) Make changes to available fields, and then click Save.
Fields Description
Name A name for the sensor or actuator.
Description Any descriptive text you want.
Location (X, Y Describe the sensor's or actuator's location in the data center by typing alphanumeric values for the
and Z) X, Y and Z coordinates. See
If the term "Rack Units" appears in parentheses in the Z location, you must type an integer number.
The Z coordinate's format is determined on the page of Peripherals.
Alarmed to
Normal Delay
This field is available for the DX2‑PIR presence detector only.
It determines the wait time before the PRO3X announces that the presence detector is back to
normal after it already returns to normal.
Adjust the value in seconds.
Binary Sensor
Subtype
This field is available for any Server Technology contact closure sensor except for
DX2‑DH2C2's contact closure sensors.
Determine the sensor type of your contact closure detector.
• •
• •
• •
• •
144
Sensor/Actuator Location Example: X, Y, Z Coordinates
Contact Closure detects the door lock or door open/closed status.
Smoke Detection detects the appearance of smoke.
Water Detection detects the appearance of water on the floor.
Vibration detects the vibration of the floor.
(on page 147)
