LEGRAND Server Technology PRO3X User Manual page 245

4) By default, the SMTP server specified on the SMTP Server page will be the SMTP server for
performing this action.
To use a different SMTP server, select the 'Use custom settings' radio button.
Default messages are sent based on the event.
5) If needed, you can customize the subject and messages sent via this email.
• • Select the 'Custom subject' checkbox, and enter the text you prefer as this email's subject.
• Select the 'Use custom log message' checkbox, and then create a custom message up to 1024 •
characters in the provided field.
• To automatically insert message placeholders, open the Custom Log Message Help section. Search •
for placeholders and click to include them in your message.
6) Click Create.
Send Sensor Report
You may set the PRO3X so that it automatically reports the latest readings or states of one or multiple
sensors by sending a message or email or simply recording the report in a log. These sensors can be
either internal or environmental sensors listed below.
• •
Inlet sensors, including RMS current, RMS voltage, active power, apparent power, power factor and
active energy.
• • Outlet sensors, including RMS current, RMS voltage, active power, apparent power, power factor,
active energy and outlet state (for outlet-switching capable PDUs only).
• •
Overcurrent protector sensors, including RMS current and tripping state.
• • Peripheral device sensors, which can be any environmental sensor packages connected to the
PRO3X, such as temperature or humidity sensors.
SeeSend Sensor Report Example
▶
Operation:
1) Choose Device Settings > Event Rules >
2) Select 'Send sensor report' from the Action list.
3) In the 'Destination actions' section, select the method(s) to report sensor readings or states. The
number of available methods varies, depending on how many messaging actions have been created.
The messaging action types include:
• • Log event message
• • Syslog message
• • Send email
• Send SMS message •
4) If no messaging actions are available, create them now.
5) In the 'Available sensors' field, select the desired target's sensor.
a. a. Click the first
(on page 252).
to select a target component from the list.
.
245
