Dual Ethernet Connection

• •
ETH1 and ETH2 both support up to 1000 Mbps.
Exception: USB-cascading chains have different requirements.
▶
Check list when connecting both ports to the networks:
• • Both Ethernet interfaces are connecting to different subnets.
• •
Both Ethernet interfaces have been enabled. By default both are enabled.
• •
Both Ethernet interfaces are configured with proper IPv4 and/or IPv6 settings.
• • It is NOT required that the two Ethernet interfaces share similar network settings. For example,
you can enable IPv4 settings in one interface but enable IPv6 settings in the other, or apply static
IP to one but DHCP IP to the other.
• •
The cascading mode is disabled. By default it is disabled. Go to Device Settings > Network.

Configuring the PRO3X

You can initially configure via one of the following:
• •
A TCP/IP network that supports DHCP
• • A mobile device with PDView installed
• •
A computer physically connected to the PDU
Basic configuration process overviews:
▶
Configuration via a DHCP‑enabled network:
1) Connect the PRO3X to a DHCP IPv4 network.
2) Use the front panel LCD display to retrieve the IP address.
3) Launch a web browser to configure the PRO3X.
▶
Configuration via a connected mobile device:
1) Download the PDView app to your mobile device.
2) Connect the mobile device to PRO3X via USB.
3) Launch PDView to configure the PRO3X.
