Modifying An Outlet Group - LEGRAND Server Technology PRO3X User Manual

• •
You can reset the energy counter and minimum/maximum values of other readings for one or more
outlet groups at a time on the Outlet Groups page.
• •
To reset these values for a single outlet group, there are two methods -- either Outlet Groups page
or individual group page.
• • Resetting an outlet group's energy counter has NO impact on any member outlet's energy counter.
You must have the Administrator Privileges to reset these values.
Available on models with outlet-metering
▶
To reset values on the Outlet Groups page:
1) On the Outlet Groups page, select one or more outlet groups to reset.
2) Click > Reset Energy Counter, or Reset Minimum/Maximum, then confirm the operation when
prompted.
▶
To reset values on a specific outlet group's page:
1) On the Outlet Groups page, click a group name to open its page
2) Scroll down to the Settings section.
3) Click the Reset button to either "Reset energy counter" or Reset minimum/maximum.
4) Click to confirm the reset.

Modifying an Outlet Group

To modify an outlet group, you must have either permission below.
• •
Administrator Privileges
• • Change Pdu, Inlet, Outlet & Overcurrent Protector Configuration
▶
To modify the member outlets:
1) On the Outlet Groups page, click a group name to go to its details page.
2) Click Edit Members.
3) Add or remove outlets of this group by selecting or clearing checkboxes.
4) Click Save.
▶
To change the group name:
1) Scroll down to the Settings section, then click Edit Settings.
2) Type a new name.
3) Click Save.
▶
To configure the thresholds of group sensors:
1) Click the Thresholds title bar at the bottom of the page to display thresholds.
125
