Interface list:
Interface Description
name
BRIDGE
When another wired network is connected to the Ethernet port of
your PRO3X, and your PRO3X has been set to the bridging mode,
select this interface name instead of the Ethernet interface.
ETH1
When another wired network is connected to the ETH1 port of your
PRO3X, select this interface name.
ETH2
When another wired network is connected to the ETH2 port of your
PRO3X, select this interface name.
WIRELESS
When another wireless network is connected to your PRO3X, select
this interface name.
Setting the Cascading Mode
See the Cascading Solution Guide for full details on network setup, physical setup, and supported
configurations for all cascades across products. The sections documented here are a brief overview.
The cascading mode configured on the primary device determines the Ethernet sharing method, which
is either network bridging or port forwarding. The cascading mode of all devices in the chain must be
the same.
You must have the Change Network Settings permission to configure the cascading mode.
Note: Port Forwarding mode does not support APIPA.
▶
To configure the cascading mode:
1) Choose Device Settings > Network > Common Network Settings section.
2) Select the preferred mode in the Cascading Mode field.
Mode Description
None
No cascading mode is enabled. This is the default.
Bridging
Each device in the cascading chain is accessed with a different
IP address.
Port Forwarding
Each device in the cascading chain is accessed with the same
IP address(es) but with a different port number assigned.
Tip: If selecting Port Forwarding, the Device Information page will show a list of port numbers for all
cascaded devices. Choose Maintenance > Device Information > Port Forwarding.
3) For the Port Forwarding mode, you must also configure the following settings.
Note that if either setting below is incorrectly configured, a networking issue occurs.
