Field/setting
Authentication
Pre-Shared Key
Outer
authentication
Inner
authentication
Identity
Password
166
Description
Select an authentication method.
• • No Authentication: No authentication data is required.
• •
PSK: A Pre-Shared Key is required.
• • EAP: PRO3X supports 802.1X (EAP) Network Authentication.
Enter required authentication data in the fields that appear.
This field appears only when PSK is selected.
Type the PSK string.
This field appears when 'EAP' is selected.
There are two authentication methods for EAP.
• •
PEAP: A TLS tunnel is established, and an inner
authentication method can be specified for this tunnel.
• •
TLS: Authentication between the client and authentication
server is performed using TLS certificates.
This field appears when both 'EAP' and 'PEAP' are selected.
• • MS‑CHAPv2: Authentication based on the given password
using MS‑CHAPv2 protocol.
• • TLS: Authentication between the client and authentication
server is performed using TLS certificates.
This field appears when 'EAP' is selected.
Type your user name.
This field appears only when 'EAP', 'PEAP' and 'MS-
CHAPv2' are all selected.
Type your password.
