Field/setting
User search
subfilter
Group lookup
using memberOf
attribute
Group member
attribute
Group entry object
class
Group search
subfilter
Active Directory
domain
1) Click Add Server. The new LDAP server is listed. To verify, click Test Connection to check whether the
PRO3X can connect to the new server successfully.
2) To add more servers, repeat the same steps.
3) In the LDAP page, use the arrow buttons to arrange the servers in the order they should be
accessed, then click Save.
4) Make sure LDAP is enabled: Go to Device Settings > Security > Authentication, and select LDAP as
the Authentication Type.
202
Description
Search criteria for finding LDAP user objects within the directory tree.
• •
Select this checkbox to determine group membership by consulting the user's
memberOf attribute(s).
• •
Deselect this checkbox to determine group membership by doing a non-recursive
search for groups containing the user's DN as member.
• • Required only when "Group lookup using memberOf attribute" is not selected.
• •
Required for OpenLDAP only.
• •
Required only when "Group lookup using memberOf attribute" is not selected.
• • Required for OpenLDAP only.
• •
Required only when "Group lookup using memberOf attribute" is not selected.
• •
Required for OpenLDAP only.
The name of the Active Directory Domain.
• •
Example: testradius.com
