The following diagram shows a sample 0U front panel display.
Use the front panel display to view information and even administer features on supported models. It
consists of:
• •
LCD display
• • Four control buttons
Zero U models automatically adjust the orientation of the content shown after detecting the direction
of installation. You can also manually change the orientation.
Note: All front panel display images in the User Guide are for Zero U models with the LCD front panel
display. Displays may differ slightly by model.

Automatic and Manual Modes

After powering on or resetting, the front panel display first shows some dots, then logo and finally
enters the automatic mode.
▶
Automatic mode without alerts available:
In this mode, the display cycles through information as long as there are no alerts.
▶
Manual mode:
To view more information or control outlets, enter manual mode.
Press or
To return to the automatic mode, press
66
to enter the manual mode, where the Main Menu is first displayed.
until you return to the main display.
