Event types
Device connection
or disconnection,
such as a
USB‑cascaded
device
+12V Supply 1
Status
Xerus Default Log Messages for All Products
Listed here are all default messages for all Xerus events, including all supported products. Not all
products support all events, and events are marked here with the supported model type.
Event/context
Asset Management >
Blade Extension
Overflow
Asset Management >
Composite Asset Strip
Composition Changed
Asset Management >
Device Config Changed
Asset Management >
Firmware Update
Asset Management >
Rack Unit > Blade
Extension Connected
Asset Management >
Rack Unit > Tag
Connected
218
Radio buttons
• •
Connected: action occurs only when the selected device is
physically connected to it.
• • Disconnected: action occurs only when the selected device
is physically disconnected from it.
• • Both: action occurs both when the selected device is
physically connected to it and when it is disconnected.
Available radio buttons include "Fault," "OK" and "Both."
• •
Fault: action occurs only when the selected 12V power
supply to the controller enters the fault state.
• • OK: action occurs only when the selected 12V power supply
to the controller enters the OK state.
• • Both: action occurs whenever the selected 12 power
supply's status changes.
Default message on event assertion
Blade extension overflow occurred on strip
[AMSNUMBER] ('[AMSNAME]').
Composition changed on composite asset
strip [AMSNUMBER] ('[AMSNAME]').
Config parameter '[CONFIGPARAM]' of asset
strip [AMSNUMBER] ('[AMSNAME]') changed
to '[CONFIGVALUE]' by user '[USERNAME]'.
Firmware update for asset strip
[AMSNUMBER] ('[AMSNAME]'): status
changed to '[AMSSTATE]'.
Blade extension with ID '[AMSTAGID]'
connected at rack unit
[AMSRACKUNITPOSITION] of asset strip
[AMSNUMBER] ('[AMSNAME]').
Asset tag with ID '[AMSTAGID]' connected at
rack unit [AMSRACKUNITPOSITION], slot
[AMSBLADESLOTPOSITION] of asset strip
[AMSNUMBER] ('[AMSNAME]').
Default message on event
deassetion
Blade extension overflow cleared for
strip [AMSNUMBER] ('[AMSNAME]').
Blade extension with ID
'[AMSTAGID]' disconnected at rack
unit [AMSRACKUNITPOSITION] of
asset strip [AMSNUMBER]
('[AMSNAME]').
Asset tag with ID '[AMSTAGID]'
disconnected at rack unit
[AMSRACKUNITPOSITION], slot
[AMSBLADESLOTPOSITION] of asset
strip [AMSNUMBER] ('[AMSNAME]').
Model
Type
