LEGRAND Server Technology PRO3X User Manual page 268

After configuring the destination and authentication settings, do either or both of the following:
• •
To perform the data push after the occurrence of a certain event, create the data push action and
assign it to an event rule.
• • To push the data at a regular interval, schedule the data push action.
▶
To configure data push settings:
1) Choose Device Settings > Data Push.
2) To specify a destination, click
3) Set up the URL field.
a. Select http or https. a.
b. b. Type the URL or host name in the accompanying text box.
4) If selecting https, a CA certificate is required for making the connection. Click Browse to install it.
Then you can:
• Click Show to view the certificate's content. •
• • Click Remove to delete the installed certificate if it is inappropriate.
5) If the destination server requires authentication, select the 'Use authentication' checkbox, and enter
the following data.
• User name comprising up to 64 characters •
• • Password comprising up to 128 characters
6) Click Create.
7) Repeat the same steps for additional destinations. Up to 64 destinations are supported.
268
.
