To log in using HyperTerminal:
1) Connect your computer to the product via a local connection.
2) Launch HyperTerminal on your computer and open a console window. When the window first
opens, it is blank.
Make sure the COM port settings use this configuration:
• • Bits per second = 115200 (115.2Kbps)
• Data bits = 8 •
• Stop bits = 1 •
• Parity = None •
• Flow control = None •
Tip: For a USB connection, you can determine the COM port by choosing Control Panel > System >
Hardware > Device Manager, and locating the "Device Serial Console" under the Ports group.
3) In the communications program, press Enter to send a carriage return to the PRO3X. The Username
prompt appears.
4) Type a name and press Enter. The name is case sensitive. Then you are prompted to enter a
password.
5) Type a password and press Enter. The password is case sensitive.
After properly entering the password, the PRO3X name appears at the prompt.
Tip: The 'Last login' information, including the date and time, is also displayed if the same user account
was used to log in to this product's web interface or CLI.
6) You are now logged in to the command line interface and can begin using commands.

With SSH or Telnet

You can remotely log in to the command line interface (CLI) using an SSH or Telnet client, such as PuTTY.
Note: PuTTY is a free program you can download from the Internet. Refer to PuTTY's documentation for
details on configuration.
▶
To log in using SSH or Telnet:
1) Ensure SSH or Telnet has been enabled.
2) Launch an SSH or Telnet client and open a console window. A login prompt appears.
3) Type a name and press Enter. The name is case sensitive.
Note: If using the SSH client, the name must NOT exceed 25 characters. Otherwise, the login fails.
