Field/setting Description
Enable verification Select this checkbox if it is required to validate the LDAP server's certificate by the PRO3X
of LDAP server prior to the connection.
certificate
If the certificate validation fails, the connection is refused.
CA certificate Consult your AA server administrator to get the CA certificate file for the LDAPS server.
Click Browse to select and install the certificate file.
• • Click Show to view the installed certificate's content.
• •
Click Remove to delete the installed certificate if it is inappropriate.
Note: If the required certificate file is a chain of certificates, and you are not
sure about the requirements of a certificate chain, see TLS Certificate Chain.
• •
Select this checkbox to make the authentication succeed regardless of the certificate's
Allow expired and
validity period.
not yet valid
certificates
• •
After deselecting this checkbox, the authentication fails whenever any certificate in
the selected certificate chain is outdated or not valid yet.
Anonymous bind Use this checkbox to enable or disable anonymous bind.
• •
To use anonymous bind, select this checkbox.
• • When a Bind DN and password are required to bind to the external LDAP/LDAPS
server, deselect this checkbox.
Bind DN Required after deselecting the Anonymous Bind checkbox.
Distinguished Name (DN) of the user who is permitted to search the LDAP directory in the
defined search base.
Bind password, Required after deselecting the Anonymous Bind checkbox.
Confirm bind Enter the Bind password.
password
Base DN for search Distinguished Name (DN) of the search base, which is the starting point of the LDAP
search.
• •
Example: ou=dev,dc=example,dc=com
Login Name The attribute of the LDAP user class which denotes the login name.
Attribute
• • Usually it is the uid.
User entry object The object class for user entries.
class
• •
Usually it is inetOrgPerson.
