Field
*Outlet state on
power up
*Outlet
initialization delay
on power up
*Power off period
during power
cycle
*Inrush guard
delay
1) Click Save.
▶
To reset ALL energy counters:
An energy reading is a value of total accumulated energy, which is never reset, even if the power fails or
the PRO3X is rebooted. However, you can manually reset this reading to restart the energy
accumulation process. Only users with the "Admn" role assigned can reset energy readings.
Note: This reset button does not reset the energy values of outlet groups. Go to the Outlet Groups page
to reset that value.
1) On the PDU page, in the Settings section, make sure Edit Settings is not clicked, or cancel out of
editing settings.
2) On the Reset all energy counters option, click Reset, then click on the confirmation message.
• • All energy readings are reset to zero.
Tip: You can also reset the energy reading of an individual inlet or outlet on those pages.
94
Function
Determines the initial power state of ALL
outlets after the PRO3X powers up.
• •
Options: on, off, and last known
See Options for Outlet State on Power Up
(on page 96)
Determines how long the PRO3X waits before
providing power to all outlets after recovering
from a temporary power loss.
• •
Range: 1 second to 1 hour
Determines the power-off period after the
outlet is switched OFF during a power cycle.
• •
Range: 1 second to 1 hour
Prevents a circuit breaker trip due to inrush
current when many devices connected to the
PDU are turned on.
• •
Range: 100 milliseconds to 10 seconds
Note
• •
After removing power from the PDU, you
must wait for a minimum of 10 seconds
before powering it up again. Otherwise, the
default outlet state settings may not work
properly.
• •
You can override the global outlet state
setting on a per-outlet basis so specific
outlets behave differently on power up.
Configure this on the individual outlet page.
• •
See Initialization Delay Use Cases
96).
• •
Power cycling the outlet(s) turns the
outlet(s) off and then back on.
• •
You can override this global power cycle
setting on a per-outlet basis so specific
outlets' power-off period is different.
See Inrush Current and Inrush Guard Delay
page 97).
(on page
(on
