State
normal
below lower critical "R" < Lower Critical threshold
below lower
warning
above upper
warning
above upper critical Upper Critical threshold < "R"
alarmed
unavailable
Note that for a contact closure sensor, the normal state depends on the normal setting you have
configured.
Managed actuator states:
State
Description
on
The actuator is turned on.
off
The actuator is turned off.
unavailable
Unmanaged sensor/actuator states:
State
Description
unmanaged Sensors or actuators are physically connected to the PRO3X but not
managed yet.
Note: Unmanaged sensors or actuators will disappear from the web interface after they are no longer
physically connected.

Finding the Sensor's Serial Number

A sensor package has a serial number tag attached to its rear side.
138
Description
For numeric sensors, it means the readings are within the
normal range.
For state sensors, it means they enter the normal state.
Lower Critical threshold <= "R" < Lower Warning threshold
Upper Warning threshold < "R" <= Upper Critical threshold
The state sensor enters the abnormal state.
Communication with the managed sensor is lost.
-- OR --
Sensor packages are upgrading their sensor firmware.
Communication with the managed actuator is lost.
-- OR --
Sensor packages are upgrading their sensor firmware.
