Mode
Inlet overview
• To enable the front panel outlet-switching function, select the 'Outlet switching' checkbox. •
• To enable the front panel actuator-control function, select the 'Peripheral actuator control' •
checkbox.
• • The built-in beeper's mute control function is enabled per default. To disable it, deselect the 'Mute
beeper' checkbox.
• • By default the front panel RCM self-test function, if available, is enabled.
3) Click Save.
If the 'Mute beeper' feature is enabled, you can operate the front panel to mute it whenever it
beeps.
Or you can turn on or off outlets/actuators by operating the front panel.

Configuring the Serial Port

You can change the bit rate of the serial port labeled CONSOLE / MODEM that is present on some
models. The default bit rate for console and modem operation is 115200 bps.
The following devices are supported via the serial interface:
• • A computer for console management.
• •
A Raritan KVM product.
• •
An analog modem for remote dial-in and access to the CLI.
• •
A GSM modem for sending out SMS messages to a cellular phone.
Bit-rate adjustment may be necessary. Change the bit rate before connecting the supported device to
the PRO3X through the serial port, or there are communication problems.
You can set diverse bit-rate settings for console and modem operations. Usually the PRO3X can detect
the device type, and automatically apply the preset bit rate.
The PRO3X will indicate the detected device in the Port State section of the Serial Port page.
To configure serial port and modem settings, choose Device Settings > Serial Port.
▶
To change the serial port's baud rate settings:
1) Click the 'Connected device' field to make the serial port enter an appropriate state.
Options
Automatic
detection
Force console
278
Data entered
The LCD display cycles through the inlet information only.
Description
The PRO3X automatically detects the type of the device connected to the
serial port.
Select this option unless your PRO3X cannot correctly detect the device
type.
The PRO3X attempts to recognize that the connected device is set for the
console mode.
