Add a new LDAP server:
config:# authentication ldap add <host> <port> <ldap_type> <security>
<bind_type> <base_DN> <login_name_att> <user_entry_class> "Optional
Parameters"
Note: "Optional Parameters" refer to one or multiple parameters listed in the section Optional
Parameters. They are required only when your server settings need to specify these parameters. For
example, if setting the <bind_type> to "authenticatedBind", then you must add the parameter
"bindDN" to this command.
When the above command is successfully performed, a list of all LDAP servers, including the newly-
added one, will be displayed, which is similar to the following diagram.
Variables:
• • <host> is the IP address or host name of the LDAP server.
• •
<port> is the port number assigned for communication with the LDAP server.
• •
<ldap_type> is one of the LDAP server types: openldap or activeDirectory.
Type
openldap
activeDirectory
• •
<security> is one of the security options: none, startTls or tls.
Type
none
startTls
tls
• •
<bind_type> is one of the bind options: anonymouseBind, or authenticatedBind.
Type
anonymousBind
Description
OpenLDAP server
Microsoft Active Directory
Description
No security
StartTLS
TLS
Description
Enable the anonymous Bind.
Bind DN and password are NOT required.
