Determine the CONSOLE baud rate:
config:# serial consoleBaudRate <baud_rate>
Note: The serial port bit-rate change is required when the PRO3X works in conjunction with Raritan's
Dominion LX KVM switch. Dominion LX only supports 19200 bps for communications over the serial
interface.
▶
Determine the MODEM baud rate:
config:# serial modemBaudRate <baud_rate>
Variables:
• •
<baud_rate> is one of the baud rate options: 1200, 2400, 4800, 9600, 19200, 38400, 57600,
115200.
Forcing the Device Detection Mode
This command forces the serial port on the PRO3X to enter a specific device detection mode.
config:# serial deviceDetectionType <mode>
Variables:
• • <mode> is one of the detection modes: automatic, forceConsole, forceAnalogModem, or
forceGsmModem.
Option
automatic
forceConsole
forceAnalogModem The PRO3X attempts to recognize that the connected device
forceGsmModem
Example - Baud Rate
The following command sets the CONSOLE baud rate of the PRO3X device's serial port to 9600 bps.
462
Description
The PRO3X automatically detects the type of the device
connected to the serial port.
Select this option unless your PRO3X cannot correctly
detect the device type.
The PRO3X attempts to recognize that the connected device
is set for the console mode.
is an analog modem.
The PRO3X attempts to recognize that the connected device
is a GSM modem.
