Using the Command Line Interface

This section explains how to use the command line interface (CLI) to administer the PRO3X.
Note that available CLI commands are model dependent.
CLI commands are case sensitive.
The CLI can be used to:
• •
Reset
• •
Display the device and network information, such as the device name, firmware version, IP address,
and so on
• •
Configure the device and network settings
• • Troubleshoot network problems
You can access the interface over a local connection using a terminal emulation program such as
HyperTerminal, or via a Telnet or SSH client such as PuTTY.
Note: Telnet access is disabled by default. To enable Telnet, go to Device Settings > Network Services >
Telnet.
In This Chapter
Logging in to CLI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 324
Tips for Using the CLI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
Showing Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
Clearing Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354
Configuring the Device and Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354
Network Troubleshooting in Diagnostic Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . 472

Logging in to CLI

Logging in via HyperTerminal over a local connection is a little different than logging in using SSH or
Telnet.
If a security login agreement has been enabled, you must accept the agreement in order to complete
the login. Users are authenticated first and the security banner is checked afterwards.

With HyperTerminal

You can use any terminal emulation programs for local access to the command line interface.
This section illustrates HyperTerminal, which is part of Windows operating systems prior to Windows
Vista.
