Tip: If you manually perform any power operations on non-critical outlets during the load shedding
mode, the icons vary. See
• The message "Load shedding active" appears next to the 'Outlets' title.
• If the Non-Critical column was hidden, it automatically is shown when load shedding mode is
activated.
To deactivate load shedding mode:
1) On the Outlets page, click
2) Click Deactivate on the confirmation message.
Now you can turn on/off any outlets.
TIP -- automatic load shedding via contact closure sensors:
If you have connected a contact closure sensor, you can set up an event rule in a manner that this
sensor's status change automatically activates or deactivates the load shedding mode. See
Environmental-Sensor-Level Event Rule
Off and Lock Icons for Outlets
This section further explains the following two icons for outlets, which display in the load shedding
mode.
Lock icon
: It means the outlet WILL be automatically powered on after deactivating the load
shedding mode.
Off icon
: It means the outlet will remain powered OFF when deactivating the load shedding
mode.
Which outlets show the lock icon
Non‑critical outlets that were powered ON prior to the load shedding mode
Non‑critical outlets that you manually switch on during the load shedding mode
Off and Lock Icons for Outlets
> Deactivate Load Shedding.
(on page 262).
:
(on page 115).
Sample
115
