Example:
• Assign a Default Gateway.
Enable Interface:
Make sure the Ethernet interface is enabled, or all networking through this interface fails. This setting is
available in the ETH1/ETH2 or ETHERNET section, but not available in the BRIDGE section.
Other Ethernet settings:
Field
Description
Speed
Select a LAN speed.
Duplex
Select a duplex mode.
Show the LAN's current status, including the current speed and
Current state
duplex mode.
MTU
Enable LLDP
When LLDP is enabled, device discovery is possible with
LLDP management software that is often present in network
switches.
Authentication
Select an authentication method.
162
fd07:2fa:6cff:1111::0/128
Auto: System determines the optimum LAN speed
through auto-negotiation.
10 MBit/s: Speed is always 10 Mbps.
100 MBit/s: Speed is always 100 Mbps.
1 GBit/s: Speed is always 1 Gbps (1000 Mbps).
Auto: Selects the optimum transmission mode through
auto-negotiation.
Full: Data is transmitted in both directions
simultaneously.
Half: Data is transmitted in one direction at a time.
Set the MTU from 1280 to 1500.
Default is enabled.
No Authentication: No authentication data is required.
EAP: PRO3X supports 802.1X (EAP) Network Authentication.
You must have a client-side certificate to communicate with the
authentication server. Enter required authentication data in the
fields that appear.
