1) Adjust the brightness, contrast, saturation and gain by modifying their values or adjusting the
corresponding slide bar.
• • To customize the gain value, you must deselect the Auto Gain checkbox first.
• • To restore all settings to this webcam's factory defaults, click Set to Webcam Defaults.
▶
Settings:
1) Click Edit Settings.
2) Enter a name for the webcam. Up to 64 ASCII printable characters are supported.
• If configured to store snapshots on a remote server, the webcam's name determines the name of •
the folder where snapshots are stored.
• • It is suggested to customize a webcam's name before saving snapshots on the remote server. In
case you change the webcam's name after saving any snapshots, PRO3X will create a new folder
with the new webcam name while keeping the old folder with the old name.
3) Type the location information in each location field as needed. Up to 63 ASCII printable characters
are supported.
• • Note that the location data you enter is not available in those snapshots stored on remote servers.
Tip: If the webcam's location is important, you can customize the webcam's name based on its
location.
4) Select a resolution for the webcam.
• • If you connect two webcams to one USB‑A port using a powered USB hub, set the resolution to
352x288 or lower for optimal performance.
5) Select the webcam mode.
Mode Description
Video
The webcam enters the video mode.
• •
Set the 'Framerate' (frames per second) as needed.
Snapshot
The webcam shows static images captured by the webcam at a regular
interval.
• •
To determine the interval, set the 'Time Between Snapshots'
(seconds).
1) Click Save. The changes made to the settings are applied to the live session in the above Live Preview
section immediately.

Sending Links to Snapshots or Videos

When opening a Primary Standalone Live Preview window, a unique URL is generated for this window
session. You can email or instant message this URL to as many people as possible as long as your system
resources permit. Recipients can then click on the provided link and view live snapshots or videos
simultaneously in the Secondary Standalone Live Preview window(s).
