Field/setting Data specified
Rule name Send SNMP notifications for PDU (192.168.84.95)
inaccessibility
Event Choose Server Monitoring > 192.168.84.95 > Unreachable
Trigger condition Select the Unreachable radio button
This will make the PRO3X react only when the target PDU becomes inaccessible.
5) Select the System SNMP Notification Action.

Front Panel Settings

You can set up the default mode of the front panel display, and front panel functions for outlet
switching, actuator control, beeper mute or RCM self-test.
Note that available front panel settings are model dependent.
• •
Outlet switching -- available on outlet-switching capable models only.
• • Actuator control -- available on all models.
• •
Internal beeper's mute function -- available on all models
• •
Default front panel mode setup -- available on all models, except for the PX3-3000 series, which
does NOT provide inlet sensor information.
• •
RCM self-test -- available on those models which support residual current monitoring.
▶
To configure the front panel settings:
1) Choose Device Settings > Front Panel.
2) Configure the following:
• To configure the default view of the LCD display, select one mode below. •
Note: The default view is shown in the automatic mode.
Mode
Automatic mode The LCD display cycles through both the inlet and overcurrent
Data entered
protector information. This is the default.
Overcurrent protector information is available only when your
PRO3X has overcurrent protectors.
277
