Managing One Sensor or Actuator

If you are managing only one sensor or actuator, you can assign the desired ID number to it. When
managing multiple sensors/actuators at a time, the IDs are automatically assigned.
Tip: When the total of managed sensors/actuators reaches the maximum value, you cannot manage
additional ones. The only way to manage any sensor/actuator is to release or replace the managed
ones. To replace a managed one, assign an ID number to it by following the procedure below.
▶
To manage only one sensor/actuator:
1) Click Peripherals in the Menu.
2) Unmanaged sensors/actuators appear at the end of the list as "Manage Device". You can identify
the sensor/actuator by the Type, Serial Number, and Position columns.
3) Click the Manage Device link, and the Manage Peripheral Device dialog appears.
