4) Screw a button in the screw hole near the top. The recommended torque for the button is 1.96 N·m
(20 kgf·cm).
5) Ensure that the two buttons can engage their mounting holes in the rack or cabinet simultaneously.
6) Press the device forward, pushing the mounting buttons through the mounting holes, then letting
the device drop slightly. This secures the device in place and completes the installation.

RAMLock Outlets and Cords

PRO3X uses RamLock outlet retention mechanism, which is easy to use without any tools.
▶
RamLock Retention Mechanism:
RamLock is an ergonomic locking arm, does not require tools or other locking cords. It prevents cords
from shaking out. Cords can be quickly removed by pressing the lever.
▶
RamLock Outlets:
PRO3X has fixed 36 outlets with RamLock outlet retention mechanism (self-latching, cam-style locking
mechanism). These outlets are spaced evenly across the length of the PDU for easy cable management.
PRO3X outlets include a combination of the HDOT C13 and the innovative Server Technology HDOT Cx
hybrid outlet that accepts either C14 or C20 plugs.
