Options
Description
Force analog
The PRO3X attempts to recognize that the connected device is an analog
modem
modem.
Force GSM modem
The PRO3X attempts to recognize that the connected device is a GSM
modem.
2) Click the 'Console baud rate' field to select the baud rate intended for console management.
Note: For a serial RS‑232 or USB connection between a computer and the PRO3X, leave it at the default
(115200 bps).
3) Click the 'Modem baud rate' field to select the baud rate for the modem connected to the PRO3X.
The following modem settings/fields appear in the web interface after the PRO3X detects the
connection of an analog or GSM modem.
To configure the analog modem:
1) Select the 'Answer incoming calls' checkbox to enable the remote access via a modem. Otherwise,
deselect it.
2) Type a value in the 'Number of rings before answering' field to determine the number of rings the
PRO3X must wait before answering the call.
To configure the GSM modem:
1) Enter the SIM PIN code.
2) Select the 'Use custom SMS center number' checkbox if a custom SMS center will be used.
• Enter the SMS center number in the 'SMS center' field.
3) If needed, click Advanced Information to view detailed information about the modem, SIM and
mobile network.
4) To test whether the PRO3X can successfully send out SMS messages with the modem settings:
a.
a. Enter the number of the recipient's phone in the Recipient Phone field.
b. Click Send SMS Test to send a test SMS message.
b.

Lua Scripts

If you can write or obtain any Lua scripts, you can create or load them into the PRO3X to control its
behaviors.
Some Lua scripts examples are provided, which you can load as needed.
Note: Not all Lua script examples can apply to your PRO3X model. You should read each example's
introduction before applying them.
You must have the Administrator Privileges to manage Lua scripts.
279
