Variables:
• •
<ETH> is one of the network interfaces: ETH1/ETH2, WIRELESS, or BRIDGE. Note that you must
choose/configure the bridge interface if your PRO3X is set to the bridging mode.
Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP
parameters of ETH1/ETH2 and WIRELESS interfaces do NOT function.
Interface Description
eth1 Determine the IPv4 preferred host name of the ETH1 interface (that
is, wired networking).
eth2 Determine the IPv4 preferred host name of the ETH2 interface (that
is, wired networking).
wireless Determine the IPv4 preferred host name of the WIRELESS interface
(that is, wireless networking).
bridge Determine the IPv4 preferred host name of the BRIDGE interface (that
is, bridging mode).
• • <name> is a host name which:
• Consists of alphanumeric characters and/or hyphens •
• Cannot begin or end with a hyphen •
• • Cannot contain more than 63 characters
• • Cannot contain punctuation marks, spaces, and other symbols
Setting the IPv4 Address
After selecting the static IP configuration mode, you can use this command to assign a permanent IP
address to the PRO3X.
config:# network ipv4 interface <ETH> address <ip address>
Variables:
• •
<ETH> is one of the network interfaces: ETH1/ETH2, WIRELESS, or BRIDGE. Note that you must
choose/configure the bridge interface if your PRO3X is set to the bridging mode.
Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP
parameters of ETH1/ETH2 and WIRELESS interfaces do NOT function.
Interface Description
eth1 Determine the IPv4 address of the ETH1 interface (that is, wired
networking).
