• Group number •
• Name: the outlet group name displays as a link. Click to go to the details page for the group. •
• • Status: number of outlets with status ON, number of outlets with status OFF.
• • Active Power: The active power for the group. A sum of all member outlets' active power values.
• Maximum Active Power: Hidden by default. Click the columns icon to add this data. The highest •
recorded active power for the group.
• Outlets: A list of the outlet numbers who are members of the group. The PDU(s) of the outlets •
displays as links.

Creating an Outlet Group

You can create an outlet group if you often have to perform the same action on the same outlets at a
regular interval.
For example, create an outlet group when you need to:
• •
Power cycle specific outlets every week.
• •
Sum up and track specific outlets' active power values every month.
• • Sum up the increased values of specific outlet's active energy values every month.
Note that an outlet can be a member of one or multiple groups.
To create an outlet group, you must have either permission below.
• •
Administrator Privileges
• •
Change Pdu, Inlet, Outlet & Overcurrent Protector Configuration
▶
To create an outlet group:
1) In the Outlet Groups page, click Add Group.
2) Enter a Group name.
Tip: Outlet group names do not have to be unique. Different groups with the same group name can be
identified through their unique index numbers.
