Field Description
Outer
authentication
This field appears when 'EAP' is selected.
There are two authentication methods for EAP.
• • PEAP: A TLS tunnel is established, and an inner authentication
method can be specified for this tunnel.
• • TLS: Authentication between the client and authentication
server is performed using TLS certificates.
Inner
authentication
This field appears when both 'EAP' and 'PEAP' are selected.
• •
MS‑CHAPv2: Authentication based on the given password
using MS‑CHAPv2 protocol.
• •
TLS: Authentication between the client and authentication
server is performed using TLS certificates.
Identity
This field appears when 'EAP' is selected.
Type your user name.
Password
This field appears only when 'EAP', 'PEAP' and 'MS-CHAPv2'
are all selected.
Type your password.
Client certificate,
A client certificate is required for two scenarios: (1)
Client private key,
EAP+TLS, (2) EAP+PEAP+TLS .
Client private key
password
PEM encoded X.509 certificate and PEM encoded private key are
required for certification-based authentication methods. Private
key password is optional.
• •
Private keys in PKCS#1 and PKCS#8 formats are supported.
• • Client Private Key Password should be entered only when your
private key is encrypted with a password.
• • To view the uploaded certificate, click Show Client Certificate.
• •
To remove the uploaded certificate and private key, click 'Clear
Key/Certificate selection'.
