Option Description
1000Mbps The LAN speed is always 1000 Mbps.
Changing the LAN Duplex Mode
This command determines the LAN interface duplex mode.
config:#
Variables:
• • <ETH> is one of the options -- eth1 or eth2.
Option
eth1
eth2
• •
<mode> is one of the modes: auto, half or full.
Option Description
auto The PRO3X selects the optimum transmission mode through auto-
negotiation.
half Half duplex:
Data is transmitted in one direction (to or from the PRO3X) at a time.
full Full duplex:
Data is transmitted in both directions simultaneously.
Setting the LAN MTU
This command sets the MTU for the ethernet interface.
config:#
Variables:
• • <ETH> is one of the options -- eth1 or eth2.
• •
<mtu> is the Maximum Transfer Unit. Enter a value from 1280-1500.
Setting the Ethernet Authentication Method
PRO3X supports 802.1X (EAP) Network Authentication. Enable the ethernet interface, and then set the
authentication method.
370
network ethernet <ETH> duplexMode <mode>
Description
ETH1 port
ETH2 port
network ethernet <ETH> mtu <mtu>
